Tideway Stainless Steel Grunpump SSCH4-60 is a single phase light horizontal multistage centrifugal pump that are mainly applicability for conveying of industrial liquid, such as mineral water, soft water, pure water, clean oil and circulation, and boosting for other weak chemical-industrial medium. In other hand it also could be used in water treatment processes, industrial cleaner, air conditioning system, water supply, fertilization or metering system, heating and cooling for industrial process. The material of the pump is stainless steel with two pole induction motor that could convey the liquid with the temperature within -15~70°C, hot water less than 105°C, non explosive, flammable and not aggressive to stainless steel without solid grains or fibers. Tideway Stainless Steel Grunpump SSCH4-60 are features with sturdy construction with adopted hydraulic bulge technology, compact design, multi-purpose and transport a wide range of liquid.
Stable operation even if there is presence of air in the liquid.
Light horizontal multistage centrifugal pump with compact structure that occupy small area and easy installation.
High strength and heavy duty performance.
It could be implement as a water supply, irrigation, industrial liquid conveying, water treatment and etc.
Convey weak chemical industrial liquid
Lower noise and minimal vibration.
Transportation liquid characteristics:
Temperature : -15~70°C
Hot water Temperature : < 107°C
Specific weight : ≤ 1g/cm³
Velocity rate : 1mm²/s
Surrounding Temperature : 50°C
Working pressure : ≤ 10 bar
Transportable liquid must be non explosive, flammable, not aggressive to stainless steel without solid particles and fibers.
